Turn the Key and watch as pure, fresh honey flows right out of the hive and into your jar.
No mess, no fuss, no heavy lifting, and no expensive processing equipment.
Through the clear end-frame view, you can see when the honey is ready without opening up the hive.
The extraction process is so gentle, the bees barely notice at all.
Our honey flow system makes the extraction process far less stressful for the bees and so much easier for the beekeeper
This is our potented products in china and we have own model mahines, production flowes.
Ourput/day: 16sets/machine and 64sets for four machines.
honey bee hive flow frame pecification
Name 】Chinese Honey Bee Flow Hive
【 Material 】Cedarwood
【Packaging】Wooden House Package Content:1 X Gable Roof; 1 X Inner Cover;1 X Super Box; 1 X broodBox;
1 X Bottom Board
Auto Frames Package Content : 7 X Auto Frames; 7 X Honey Tubes;1 X Metal Key;1 X User Manual .
Package Includes 2 Cartons: one carton of wooden house , one carton of 7 pcs auto frames.
Wooden House Carton—— Gross Weight:15.01kg; Packing Size:61cm X 42.5cm X 24cm
Auto Frame Carton—— Gross Weight:9.75kg; Packing Size:55.5cm X 52.5cm X 27.5cm
【 Size 】Hive Size:51cm X 41cm X 69cm
Frame Size: 7 Frames of Langsforth Size:49cm X 46.5cm X 24.5cm X 5cm
【 Feature 】Chinese auto flowing hive is a beehive designed to allow honey to be extracted simply by turning a lever: the hive does not have to be opened and the bees are not disturbed as in normal extraction. The frames contain a partially-formed plastic honeycomb lattice with vertical gaps. Bees fill in these gaps with beeswax and the cells with honey. When the mechanism of the frames is activated, the vertical gaps are offset by one half of a cell, breaking the wax seal and allowing the honey to flow down through the cells into a channel at the base of each frame and out into a collection vessel. The system is then reset and the bees remove the capping and refill the cells, beginning the process again.Chinese auto flow hive uses food-certified plastic in the honey super only, allowing the bees to produce their own natural wax comb in the brood nest.
Our package includes:
2 X Frames ( 49.5cmX24.5cmX5cm)
8 X M4 Stainless Steel Screws
4 X Replacement Parts
2 X Tubes to drain honey out
1 X Stainless Steel Key Tool
1 X English User Manual
1. For samples, 1-3 days after payment received.
2.For small order, 7-10 days after payment received.
3.For bulk order (over our MOQ),15-30 days after payment received.
1.Total weight under 30kgs, cargoes be made by Interantional Express or by air freight .
2.Total weight over 45kgs or 1CBM, cargoes will be shipped by sea or by air freight.
